Swagelok SS-4H-SC11 is a straight pattern, manual actuation stainless steel bellows sealed valve equipped with 1/4 in. tube fitting end connections. Designed to isolate system fluids and achieve reliable, leak-tight performance, this valve utilizes a robust packless design and a welded seal. Bellows valves are ideal for critical applications where the seal to atmosphere is of utmost importance, ensuring zero leakage of process media. This specific model undergoes special cleaning and packaging (SC-11) to meet stringent requirements, making it suitable for both general industrial and demanding high-purity service environments.

Specifications

Specification	Value
Body Material	316 Stainless Steel
Cleaning Process	Special Cleaning and Packaging (SC-11)
Connection 1 Size	1/4 in.
Connection 1 Type	Swagelok® Tube Fitting
Connection 2 Size	1/4 in.
CV Maximum	0.28
Maximum Temperature, °F (°C)	600 (315)
Minimum Temperature, °F (°C)	-80 (-62)
Stem Tip Material	Stainless Steel Stem Tip
eClass (4.1)	37010201
eClass (5.1.4)	37010201
eClass (6.0)	37010201
eClass (6.1)	37010201
eClass (10.1)	37010201
UNSPSC (4.03)	40141600
UNSPSC (10.0)	40141609
UNSPSC (11.0501)	40141609
UNSPSC (13.0601)	40141609
UNSPSC (15.1)	40141609
UNSPSC (17.1001)	40141609

WARNING

Do not mix/interchange Swagelok products or components not governed by industrial design standards, including Swagelok tube fitting end connections, with those of other manufacturers.
